Description

• Place of Origin : Tianjin, China
• Brand Name : TXED
• Model Number : E Times Tour
• Gears : 7 Speed
• Range per Power : > 60 km
• Frame Material : Aluminum Alloy
• Wheel Size : 20″
• Max Speed : <30km/h
• Voltage : 48V
• Power Supply : Lithium Battery
• Braking System : Mechanical Disc Brake
• Torque : 30-50 Nm
• Charging Time : >3 hours
• Motor position : Rear Hub Motor
• Battery Position : Under Saddle
• Battery Capacity : 15.6Ah
• Smart Type : Electronic
• Product name : e motor bike
• Fork : 20″x 4.0 alloy fork, integrated with the handlebar
• Frame : 20″x 4.0, Alloy 6061
• Battery : 48V/15.6AH Lithium battery
• Electric System : LCD panel
• Brake Set : Mechanical Disc Brake
• Gear Set : SHIMANO 7 speed
• Rim : 20×4.0x13Gx36H,alloy single wall
• Handle bar & Stem : Alloy handlebar, alloy stem
• Tire : 20″x4.0″ A/V, black color

Mechanical Equipment
Frame	20″x4.0, alloy, TIG welded
Fork	20″x4.0, alloy double crown rigid fork
Handlebar	alloy handlebar, black
Brake Set	front and rear disc brakes, TEKTRO, with electric brake levers
Crank Set	alloy black crank, steel chainrings
F/R Hub	front alloy hub, rear hub motor
Gear Set	SHIMANO ALTUS rear 7-speed
Weight	30.8kg
Electric System
Motor	Brushless 48V/250W rear motor
Battery	48V/15.6Ah Lithium battery cells
Mode and Other Components	throttle/pedelec with speed sensor and center LCD panel
Max Speed	32km/h
Distance per Charge	80km in average
Option	rear carrier with light or reflector, wind screen, rear basket
